USB Digimode Interface for AlincoTransceivers allowing you to utilise software such as WSJT-X, FLDigi, DM780, Echolink, DM780, N1MM Logger, MixW and many more.
The Digimode-3 interface provides a single USB connection to your PC
and has abuilt-in USB Sound Card for digital mode operation. The Tx/Rx audio signals are galvanically isolated by Bourns 600:600 Ohm transformers and the built-in VOX PTT is opto-isolated.
With this interface, you will be up and running on FT8, PSK31, Echolink, SSTV, Pactor, Packet or any mode that requires Tx/Rx Audio Interfacing between your PC and Radio within minutes.
Cable length is 1.5m from the USB port on your PC to the interface box. The cables from the interface box to the transceiver is 0.6m. The box is very compact at 80x40x20mm making it ideal to hide away behind the PC or transceiver using no desk space.
Depending on the Alinco radio, the interface will wire just to the front panel Mic as it is wired for all the audio/PTT signals or there is an additional cable tail to the external speaker port for Rx audio
The Digimode-3 instruction manual is here:
http://www.xggcomms.com/userimages/USB-Digimode-3.pdf
Alinco Transceivers have combinations of Data connectors. Use the purchase options to select the inteface you need for your radio.
Option 1
DX-77E and DX-77F(Front panel 8 Mic port used for PTT, Tx AF and Rx AF signals)
Option 2
DX-70EH, DX-70TH, DX-SR8E. DX-SR8T, DX-SR9E, DX-SR9T(Front panel 8 Mic port used for PTT & Tx AF, 3.5mm Ext Speaker jack used for Rx AF)
